Outstanding Function:

1.AT-D878UVII Plus is the upgrade two way radio of AT-D878UV PLUS. the differences between AT-D878UVII Plus & AT-D878UV Plus are the model of AT-D878UVII Plus comes with 500,000 digital contacts and Analog APRS Receiving.

2.APRS Receive

If radio GPS is positioned, the radio will display the other radio’s distance and position when radio is receiving.The APRS will be displayed on the menu of the radio when the radio GPS function is “ON”.

3. The radio comes with Built-in Bluetooth module, it can be connected to any Bluetooth headsets universally by using the Bluetooth PTT to transmit signal to your partner.



Features:

-Dual-mode ( Digital+Analog)

-1.77 inch color TFT Screen

-4000channels

-10000 Talk Groups with 500000 Digital contacts

-ETSI DMR TierⅠandⅡCompliant

-Auto-senses digital or analog reception

-Ranging function between radios with GPS

-Roaming function

-Record

-Bluetooth Walkie Talkie with Bluetooth PTT Switch



Specifications:

General

Frequency Range

VHF: 136-174MHz UHF: 400-480MHz

Memory Channels

4000

Channel Spacing

25KHz(Wide Band), 12.5KHz (Narrow Band)

Phase-locked Step

5.0/6.25KHz

Frequency Stability

±2.5ppm

Operating Temperature

-20°c to +55°c

Operating Voltage

7.4V DC±20%

Dimensions

129*61*42mm

Weight

293g(with battery pack, antenna)

Receiving Part



Wide band

Narrow band

Sensitivity(12dB SINAD

≤0.25µV

≤0.35µV

Digital Sensitivity

0.3uV/-117.4dBm(BER 5%)

0.7uV/-110dBm (BER 1%)

Adjacent Channel Selectivity

≥70db

≥60dB

Spurious Emission

≤-57dB

≤-57dB

Spurious Rejection

≥70dB

≥70dB

Blocking

84dB

Hum & Noise

≥45dB

≥40dB

Audio Distortion

≤5%

Audio Output power

1000mW/16 ohm



Transmitting Parts



Wide band

Narrow band

Output Power

VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W

Modulation Mode

±5.0KHz 25KHz

±5.0KHz 12.5KHz

Adjacent Channel Selectivity

≥70dB

≥60dB

Hum & Noise

≥40dB

≥36dB

Spurious Emission

≤-36dB

≤-36dB

4FSK Digital Modulation

12.5KHz(data) 7K60FXD

12.5KHz(data+voice) 7K60FXE

Audio Distortion

≤5%





Notes: Above Specifications are subject to change without any notice due to technology enhancement

Package Contents:

·1×Anytone AT-D878UVII Plus Radio

·1×7.4V 3100mAh Li-ion Battery Pack

·1×Bluetooth PTT

·1×USB Programming Cable

·1×Antenna

·1×Belt Clip

·1×Desktop Charger with AC adapter

·1×RadioENG Manual

·1×Bluetooth ENG Manual





Anytone AT-D878UVII Plus

SKU: NYTATii
AU$549.00 Regular Price
AU$449.00Sale Price
